歡迎光臨開平市永強風機制造有限公司官網!

Welcome to the official website of Kaiping Yongqiang Ventilation Manufacture Company Limited

銷售熱線
0750-2620888
0750-2676688
當前位置: 首 頁 / 產品中心/醇油機/alcohol oil blower/250W
吸風散熱
動力源源不斷
超靜音
高強度
FOCUS ON WIND
CREATE THE VALUE
專注風的價值 · 為客戶創造價值
好風機
永強造
2
SIZE

AVAILABLE

兩種安裝尺寸
1.輸入功率/power:250W? ? ? ? ? ?2.電壓/voltage:220V
3.轉速/speed:2800r/min2? ? ? ?4.風壓/pressure:1480Pa
5.風量/air flow:500m3/h? ? ? ? ? 6.噪音/noise:75dB(A)
7.電源線長度/wire length:0.4m

產品特性描述:

? ? ? 本產品殼體采用優質電解板拉伸而成,

電機全封閉組合,代替?zhèn)鹘y(tǒng)的鋁殼結構

另配獨立安裝板進行圓周多方位臥式安

裝,同時充分利用蝸殼的環凸設計進行

電機固定以及側隙通風。使用本產品性

價比更高,結構緊湊,自冷良好,安裝

方便。適用于各類節能灶、工程灶。

Product characteristics? ??

The shell of this product is stretched from high-quality electrolytic plates, and the motor is fully enclosed, replacing the traditional aluminum shell structure.It is equipped with an independent mounting plate for circumferential multi-directional horizontal installation, and at the same time makes full use of the ring convex design of the volute for Motor fixing and side clearance ventilation. Using this product is more cost-effective, compact structure, good self-cooling, easy to install. It is applicable to all kinds of energy-saving stoves and engineering stoves.

產品尺寸及參數
PRODUCT PARAMETERS
產品編碼:8.08.11.01.02.0003
安裝方式:臥式板
產品編碼:8.08.11.01.02.0002
安裝方式:臥式板
風機性能參數:
產品編碼 產品名稱 電壓(V) 輸入功率(W) 轉速(r/min) 風量(m3 /h) 風壓(Pa) 噪音(dBA)
8.08.11.01.02.0003 250W/中式廚用風機/A3/D款/ 220 250 2800 500 1480 75
8.08.11.01.02.0002 250W/中式廚用風機/A2/D款/ 220 250 2800 500 1480 75
產品特性描述
PRODUCT CHARACTERISTICS

? ? ? 本產品殼體采用優質電解板拉伸而成,電機全封閉組合,代替?zhèn)鹘y(tǒng)的鋁殼結構,另配獨立安裝板進行圓周多方位臥式安裝,同時充分利用蝸殼的環凸設計進行電機固定以及側隙通風。使用本產品性價比更高,結構緊湊,自冷良好,安裝方便。適用于各類節能灶、工程灶。

? ? ?The shell of this product is stretched from high-quality electrolytic plates, and the motor is fully enclosed, replacing the traditional aluminum shell structure.It is equipped with an independent mounting plate for circumferential multi-directional horizontal installation, and at the same time makes full use of the ring convex design of the volute for Motor fixing and side clearance ventilation. Using this product is more cost-effective, compact structure, good self-cooling, easy to install. It is applicable to all kinds of energy-saving stoves and engineering stoves.
