歡迎光臨開平市永強風機制造有限公司官網!

Welcome to the official website of Kaiping Yongqiang Ventilation Manufacture Company Limited

銷售熱線
0750-2620888
0750-2676688
當前位置: 首 頁 / 產品中心/蒸包爐/steam stove blower/120W
吸風散熱
動力源源不斷
超靜音
高強度
FOCUS ON WIND
CREATE THE VALUE
專注風的價值 · 為客戶創造價值
好風機
永強造
1
SIZE

AVAILABLE

一種安裝尺寸

1.輸入功率/power:120W           2.電壓/voltage:220V
3.轉速/speed:2800r/min2       4.吸力/suction:700Pa
5.風量/air flow:300m3/h          6.噪音/noise:90dB(A)
7.電源線長度/wire length:0.8m

產品特性描述:

      本產品蝸殼采用優質電解板拉伸而成,

充分利用蝸殼的環凸設計進行電機固定

以及側隙通風。產品主要為蒸包爐、煮

面桶等廚具量身定造,精心設計風葉,

吸風強勁,使用本產品性價比高,安裝

方便。

Product characteristics

The volute of this product is stretched from high-quality electrolytic plates, and the motor is fixed by making full use of the ring convex design of the volute and side clearance ventilation. The products are mainly tailor-made for kitchen utensils such as steamer ovens and noodle buckets, and the blower blades are carefully designed.Strong air suction, cost-effective use of this product, easy installation


產品尺寸及參數
PRODUCT PARAMETERS
產品編碼:8.06.14.05.02.0005
安裝方式:立式板
風機性能參數:
產品編碼 產品名稱 電壓(V) 輸入功率(W) 轉速(r/min) 風量(m3 /h) 風壓(Pa) 噪音(dBA)
8.06.14.05.02.0005 120W/蒸包爐/鐵殼鐵葉/立式板 220 120 2800 300 700 90
產品特性描述
PRODUCT CHARACTERISTICS

? ? ??本產品蝸殼采用優質電解板整體拉伸而成,充分利用蝸殼的環凸設計進行電機固定以及側隙通風。產品主要為蒸包爐、煮面桶等廚具量身定造,精心設計風葉,吸風強勁,使用本產品性價比高,安裝方便。

?The volute of this product is stretched from high-quality electrolytic plates, and the motor is fixed by making full use of the ring convex design of the volute and side clearance ventilation. The products are mainly tailor-made for kitchen utensils such as steamer ovens and noodle buckets, and the blower blades are carefully designed.Strong air suction, cost-effective use of this product, easy installation
